Viking Gear Pumps

VKNG-GEAR
  • : From Cast Iron to Stainless Steel, Packed to Mechanically Sealed - the Viking Internal Gear Pumps offered by Carotek have over 61,000 different design possibilities to meet your specific process application needs.
  • States: GA, NC, SC, TN

  • Details
  • Industry / Applications

Heavy Duty Internal Gear Pumps

Only two moving parts make these reliable and easy to maintainAdjustable end clearance accommodates low or high viscosities, high temperatures, and compensates for wearPumpsShaft Seal Options include packed gland, lip seal, single and double mechanical seal, cartridge seal and seal-less mag driveBroad selection of locations, configurations and types of porting optionsAccurate flow measurement due to minimal pulsationMetals, seals, jacketing, probes available for temperature variancesViscosity ranges from thin, thick or multiple liquidsFor motor speed operation or with gear motors, choose from compact, close-coupled optionsTypes include Universal Bracket, Universal Mag Drive, Alloy, and Motor Speed Variable Speed Pumps


Performance

PumpsMax Capacity to 1600 GPM (365 M3/Hr)Max Pressure to 250 PSI (17 BAR)Viscosity Range: 28 to 2,000,000 SSU (1 to 440,00 cSt)Temperature Range: -120 degrees F to +800 degrees F (-85 degrees C to +430 degrees C)


Viking Pump Mag Drive Pumps

The Universal Mag Drive is one of Viking Pump’s more popular Internal Gear pumps supporting applications with larger flows and more viscous fluids.

Reduces maintenance costs and downtime associated with shaft seal failure and replacement.Reduces environmental costs associated with shaft seal leakage.Minimizes installation costs when upgrading existing universal series pumps to sealless with dimensionally interchangeable footprint.Bi-directional pumping design eliminates cost of second pump for loading or unloading.3 year limited warranty

The Motor Speed Mag Drive Pump is ideal for applications with smaller flows and for thinner fluids.Viking Motor Speed Mag Drive is designed to provide positive displacement pumping capability in those situations that require the highest assurance of liquid containment. Viking Mag Drive provides for the safe, trouble-free transfer of hazardous, EPA-regulated fluids without electronic monitoring as required with mechanical face- type shaft seals.


General Purpose Pumps

Maximum application flexibility from a proven, simple pump design with only two moving partsSelf-priming pump for suction lift requirementsVarious shaft seal options for most application requirementsSelect models have UL listing availableInstalls easily with the motor mount optionDurable cast iron construction


Performance

Max Capacity to 450GPM (102 M3/Hr)Max Pressure to 250 PSI (17 BAR)Viscosity Range: to 250,000 SSU (55,00 cSt)Temperature Range: -60 degrees F to +300 degrees F (-51 degrees C to +149 degrees C)


Special Purpose Pumps

Asphalt Pumps are designed specifically to melt asphalt that has solidified in the pump prior to startup with temperature control options providing quick time to temperature In addition, to melt bitumen that has solidified in the pump, jacketing is available in bracket, head, and bearing area.

Volatile Liquid Pumps are designed exclusively to handle ammonia, LP Gas and other high vapor pressure fluids in refrigeration, filling and transfer applications. They minimize flashing by operating at low speeds.

Abrasive Fluid Pumps are designed specifically for handling slurries, paints, inks, filled asphalts, and other abrasive liquids. To extend service life and reduce total cost of ownership, they are equipped with tungsten carbide wear parts and silicon carbide mechanical seal faces. Internal Gear Pumps - Universal Seal Pump, Jacketed Pump, Magnetic Drive Pump, XPD676 Pump, Hygienic Pump, Motor Speed Pump, General Purpose Pump, Motor Speed Pump, Electrically Heated Pump, Heavy Duty Alloy Pump, Asphalt Pump, Ammonia Pump, Abrasive Liquid Pump


External Gear Pumps

Composite Mag Drive Pump, High Pressure Spur Gear Pump, Flow Dividers Contact Carotek for detailed information on models and personalized selection assistance.
Industry application include Plastics, Abrasives, Sealants, Adhesives, Agricultural, Asphalt, Biodiesel, Brewing, Beverage, Chemical, Chocolate, Ethanol, Fats & Oils, Fiber, Food, Fuels, Fuel Oils, Oil Production & Refining, Paints & Coatings, Personal Care Products, Pharmaceuticals, Polymers, Polyurethane foam, Printing Inks, Pulp & Paper, Refrigeration, Rubber, Sugar, Soaps & Detergents, Water Treatment, Wind Power.
