Armstrong Commercial Thermostatic Hot Water Mixing Valves

ARM-THRMSTTC-MXNG-VLVS
Requires Quote
  • States: GA, NC, SC, VA
  • Summary: Armstrong's thermostatic mixing valves are designed specifically for use in non-return, "dead leg" applications to provide accurate temperature control for individual and groups of fixtures.
QTY
  • Details
  • Industry / Applications
Armstrong’s thermostatic mixing valves are designed specifically for use in non-return, "dead leg" applications.

The range of products provides accurate temperature control for individual point of use (Model 215) and groups of fixtures (Models 215, 320, 425) in applications with diverse flow requirements.



Armstrong Thermostatic Hot Water Valve Model 215 Details

For Single Point of Use hot water mixing applications, the Model 215 is ideally suited for use at or near the final point of use to deliver a pre designated mixed water temperature to either a single or small 'group' of lavatories.

The Model 215 features ±2°F temperature control, adjustable maximum temperature limit stop, adjustable single temperature locking option, and thermal shutdown mode upon inlet supply failure.

The Model 215 is ASSE 1069 and 1070 Certified and is Lead-Free compliant.

Armstrong Thermostatic Hot Water Valve Model 320 and 425 Details

For Water Temperature Control for a group of fixtures, the Models 320 and 425 provides accurate temperature control where there are diverse flow requirements.  Designed specifically for 'dead leg' applications.

The Models 320 and 425 feature ±2°F temperature control, adjustable maximum temperature limit stop, adjustable single temperature locking option, and thermal shutdown mode upon inlet supply failure.  Dual thermostatic elements provide redundancy in the event of individual thermostat failure.

The Models 320 and 425 are  ASSE 1017 and CSA B125 Certified and are Lead-Free compliant.


InstitutionalHealthcareHospitalityCommercial Buildings
